Description
Engine
Gross HP: 107
PTO HP: 93
Mechanical
Chassis: 4×4 MFWD 4WD, 4×2 2WD
Final Drives: Inboard Planetary
Steering: Power
Brakes: Wet Disc
Cab: Two-post Folding ROPS, Cab optional with air-conditioning
Transmissions: 12-speed four synchronized gears with power shuttle, 12-speed mechanical shuttle, 20 speed creeper
Hydraulics
Type: Open Center
Rear Valves: 2 to 3
Pump Flow: 16.9 gpm
Total Flow: 26.6 gm
Steering Flow: 9.7 gpm
PTO
Rear PTO: Independent
Clutch: electro-hydraulic wet disc
Rear RPM: 540
Tractor Hitch
Rear Type: II
Rear Lift (at 24″): 5620 lbs
Dimensions & Tires
2WD Wheelbase: 92.2 inches
4WD Wheelbase: 89.9 inches
Weight: 6988 to 8157 pounds
Front Tire: 10×16
2WD Rear Tire: 18.4-30
Electrical
Ground: Negative
Charging System: Alternator
ROPS Charging Amps: 120
Cab Charging Amps: 150
Battery volts: 12
