Description
Engine
Gross HP: 215
Max HP: 260
PTO HP: 180
Mechanical
Chassis: 4×4 MFWD 4WD
Steering: Hydrostatic Power
Brakes: Hydraulic Wet Disc
Cab: Horizon Cab Standard with AC, Intellisteer optional
Transmissions: 18-speed full power shift, 19-speed full power shift
Hydraulics
Type: Closed Center-Load Sensing
Rear Valves: 3 to 5
Mid Valves: 3 (optional)
Pump Flow: 32 gpm, 39.5 gpm
PTO
Rear PTO: Independent
Rear RPM: 540/1000
Front PTO: Independent (optional)
Front RPM: 1000
Tractor Hitch
Rear Type: III/II
Control: Electronic Draft Control
Rear Lift (at 24″): 10746 lbs
Rear Arms: Flex Link Ends
Front Hitch: Optional
Front Lift (at ends): 8344 lbs
Dimensions & Tires
Wheelbase: 113.5
Weight: 15322 to 16094 pounds
Rear Tire: 20.8R42
Electrical
Ground: Negative
Charging System: Alternator
Charging Amps: 150, 200
Battery volts: 12
